Using a Microscope

In this worksheet, students will review their understanding of how to use a microscope, what can go wrong and how to measure specimens.

'Using a Microscope' worksheet

Key stage:  KS 3

Curriculum topic:  Biology: Structure and Function of Living Organisms

Curriculum subtopic:  Cells and Organisation

Difficulty level:

Preview

Worksheet Overview

QUESTION 1 of 10

Microscopes have helped us, as humans, to find out so much more about our world and about ourselves than people living just a couple of hundred years ago could possibly have imagined. They truly have opened up a whole new world to us!



Scientist using a microscope



So, how does a microscope work? How does it help you to see tiny things? Join Ben as he learns how to use his microscope, and see whether you can help him to improve his techniques and maybe learn something new yourself along the way!

Here is a typical light microscope:



Microscope



So why is it called a light microscope?

because it's not very heavy

because the specimens you look at are very shiny

because it uses light to shine on the specimens

Here's the microscope again:



Microscope



Which part of the microscope magnifies the object you're looking at?

magnifying glass

lens

focusing knob

Ben has been given a tiny letter on a microscope slide that he wants to look at under the microscope. He will need to do things in the correct order if he wants to see anything. Here are four things that Ben needs to do - put them in the correct order by matching each operation to the correct number.

Column A

Column B

1
turn on the light or angle the mirror so you can s...
2
place the microscope slide on to the stage
3
look from the side and move the lens down until it...
4
focus the specimen by using the focusing knob

On Ben's microscope his eyepiece lens has a magnification of x10.

His objective lens has a magnification of x20.



What is the TOTAL MAGNIFICATION he is using?

x20

x30

x200

Ben gets the tiny letter on his microscope slide into focus and it looks like this:





If he changes his x20 objective lens for a x40 lens, what will happen to the image of the letter?

it will get bigger

he won't be able to see anything

it will get smaller

Ben's friend Tom was having difficulty seeing anything at all down his microscope.



Here is a list of things that Tom might have got wrong. Tick the FIVE that would mean he couldn't see anything clearly down his microscope.

he forgot to put the slide on the microscope

he hasn't switched the microscope's light on

he hasn't got the specimen properly under the lens

his microscope isn't angled properly

the lenses are dirty

he hasn't focused correctly on the specimen

his magnification is too high

A microscope is brilliant at making tiny things visible.

Ben puts a little microscopic ruler under his microscope and this is what he sees:





The distance between each mark is 0.5mm. About how big is Ben's 'field of view' - that is, how far is it from one side to the other?

3.5mm

7mm

35mm

Ben was looking at a tiny beetle under his microscope and he used his ruler (marked in 0.5mm divisions) to measure how long it was. Look at the picture and work out the answer.



2mm

3mm

4mm

All living organisms are made of at least one little box-like structure - in most cases, millions of them! What are these little 'boxes' called?

unit

cube

cell

Ben wanted to use his microscope to look at some of those little 'boxes' from the inside of his cheek.

What's the best way for him to collect some of them to look at?

carefully scrape some off with a knife

wipe a cotton bud around the inside of his cheek

use his finger to get some from the inside of his mouth

  • ANSWERS
  • Question 1

Here is a typical light microscope:



Microscope



So why is it called a light microscope?

CORRECT ANSWER
because it uses light to shine on the specimens
EDDIE SAYS
The light microscope uses light to make the specimen (you are hoping to see) visible. The light can either come from an electric light attached to the microscope or it can be reflected light from a mirror. Either way, it's light that shines on the specimen - whereas with an eye-wateringly expensive electron microscope, it's a beam of atomic particles that makes the specimen visible.
  • ANSWERS
  • Question 2

Here's the microscope again:



Microscope



Which part of the microscope magnifies the object you're looking at?

CORRECT ANSWER
lens
EDDIE SAYS
The two lenses in the microscope contain small 'magnifying glasses' - that is convex lenses made of glass - which bend the light and so make objects appear larger than they really are.
  • ANSWERS
  • Question 3

Ben has been given a tiny letter on a microscope slide that he wants to look at under the microscope. He will need to do things in the correct order if he wants to see anything. Here are four things that Ben needs to do - put them in the correct order by matching each operation to the correct number.

CORRECT ANSWER

Column A

Column B

1
turn on the light or angle the mi...
2
place the microscope slide on to ...
3
look from the side and move the l...
4
focus the specimen by using the f...
EDDIE SAYS
Phew - that was a toughie! Having turned on the microscope light, or adjusted the little mirror, you will be able to see down the microscope, so next you pop the slide on to the stage (trying to get the specimen under the lens). Then you look from the side as you move the lens DOWN to just above the slide (because it's easy to break the slide with the lens) and then you look down the microscope and focus up, away from the slide, until the specimen comes into focus (if you're lucky!).
  • ANSWERS
  • Question 4

On Ben's microscope his eyepiece lens has a magnification of x10.

His objective lens has a magnification of x20.



What is the TOTAL MAGNIFICATION he is using?

CORRECT ANSWER
x200
EDDIE SAYS
This isn't too hard: you multiply (times) the two lenses together. So that's 10 x 20 = x200.
  • ANSWERS
  • Question 5

Ben gets the tiny letter on his microscope slide into focus and it looks like this:





If he changes his x20 objective lens for a x40 lens, what will happen to the image of the letter?

CORRECT ANSWER
it will get bigger
EDDIE SAYS
When Ben INCREASES his magnification, the letter will seem to INCREASE in size (it's been magnified!). Mind you, he probably won't be able to see much unless he changes the focus to get it nice and sharp!
  • ANSWERS
  • Question 6

Ben's friend Tom was having difficulty seeing anything at all down his microscope.



Here is a list of things that Tom might have got wrong. Tick the FIVE that would mean he couldn't see anything clearly down his microscope.

CORRECT ANSWER
he hasn't switched the microscope's light on
he hasn't got the specimen properly under the lens
the lenses are dirty
he hasn't focused correctly on the specimen
his magnification is too high
EDDIE SAYS
Microscopes are always tricky to start off with - there's so much you need to get right to see anything! If Tom forgot to put the slide on or if he didn't angle the microscope, that wouldn't stop him seeing anything. However, without light he will see nothing, the specimen has to be under the lens and if he's way out of focus or his lens is too powerful it's going to be a struggle to see much.
  • ANSWERS
  • Question 7

A microscope is brilliant at making tiny things visible.

Ben puts a little microscopic ruler under his microscope and this is what he sees:





The distance between each mark is 0.5mm. About how big is Ben's 'field of view' - that is, how far is it from one side to the other?

CORRECT ANSWER
3.5mm
EDDIE SAYS
OK, so how many gaps are there between the marks? 7, right? Each one's 0.5mm, so that's 7 x 0.5 = 3.5mm (or thereabouts!).
  • ANSWERS
  • Question 8

Ben was looking at a tiny beetle under his microscope and he used his ruler (marked in 0.5mm divisions) to measure how long it was. Look at the picture and work out the answer.



CORRECT ANSWER
2mm
EDDIE SAYS
OK, so the beetle covers FOUR of the gaps, right? They are 0.5mm each, so that's 4 x 0.5 = 2mm. Simple!
  • ANSWERS
  • Question 9

All living organisms are made of at least one little box-like structure - in most cases, millions of them! What are these little 'boxes' called?

CORRECT ANSWER
cell
EDDIE SAYS
They are cells - at least that is the name given to the tiny 'boxes' that every living thing is made of. Robert Hooke (who lived in the 1600s) was the first person to see them and thought that they looked like little prison cells.
  • ANSWERS
  • Question 10

Ben wanted to use his microscope to look at some of those little 'boxes' from the inside of his cheek.

What's the best way for him to collect some of them to look at?

CORRECT ANSWER
wipe a cotton bud around the inside of his cheek
EDDIE SAYS
That knife\'s going to be painful! And his finger ... where\'s that been since he last washed it? Ugh!! No, a cotton bud is best - he can carefully wipe that around the inside of his cheek, smear it on to his microscope slide, and then pop the bud into some disinfectant (just in case!).
